1001160000

Image is for reference, please contact us to get the real picture

Manufacturer Part
1001160000
Manufacturer
Weidmuller
Description
TERM BLOCK PLUG 3POS STR 5.08MM
Category
Connectors, Interconnects
Family
Terminal Blocks - Headers, Plugs and Sockets
Series
-
In Stock
144
Datasheets
-

1001160000 Specifications

  • Series:Omnimate BL
  • Package:Box
  • Part Status:Active
  • Type:Plug, Female Sockets
  • Number of Positions:3
  • Positions Per Level:3 (Mate), 6 (Input)
  • Number of Levels:1 (Mate), 2 (Input)
  • Pitch:0.200" (5.08mm)
  • Header Orientation:-
  • Plug Wire Entry:180°
  • Termination Style:Screwless - Leg Spring, Push-In Spring
  • Mounting Type:Free Hanging (In-Line)
  • Current - IEC:20.8A
  • Voltage - IEC:400 V
  • Current - UL:10 A
  • Voltage - UL:300 V
  • Wire Gauge or Range - AWG:12-26 AWG
  • Wire Gauge or Range - mm²:0.2-2.5mm²
  • Color:Orange
  • Operating Temperature:-50°C ~ 100°C
  • Contact Mating Finish:Tin
  • Features:Retention Latches (Non-Wire Side)
