1776422001

Image is for reference, please contact us to get the real picture

Manufacturer Part
1776422001
Manufacturer
Weidmuller
Description
TERM BLOCK HDR 8POS VERT 5.08MM
Category
Connectors, Interconnects
Family
Terminal Blocks - Headers, Plugs and Sockets
Series
-
In Stock
200
Datasheets
-

1776422001 Specifications

  • Series:Omnimate SL
  • Package:Bulk
  • Part Status:Active
  • Type:Header, Male Pins, Shrouded (4 Side)
  • Number of Positions:8
  • Positions Per Level:8
  • Number of Levels:1
  • Pitch:0.200" (5.08mm)
  • Header Orientation:Vertical
  • Plug Wire Entry:-
  • Termination Style:Solder
  • Mounting Type:Through Hole
  • Current - IEC:27.5A
  • Voltage - IEC:400 V
  • Current - UL:18.5 A
  • Voltage - UL:300 V
  • Wire Gauge or Range - AWG:-
  • Wire Gauge or Range - mm²:-
  • Color:Black
  • Operating Temperature:-50°C ~ 100°C
  • Contact Mating Finish:Tin
  • Features:Mating Flange, Solder Retention
