1508560000

Image is for reference, please contact us to get the real picture

Manufacturer Part
1508560000
Manufacturer
Weidmuller
Description
TERM BLOCK HDR 7POS 90DEG 5.08MM
Category
Connectors, Interconnects
Family
Terminal Blocks - Headers, Plugs and Sockets
Series
-
In Stock
149
Datasheets
-

1508560000 Specifications

  • Series:Omnimate SL
  • Package:Bulk
  • Part Status:Active
  • Type:Header, Male Pins, Shrouded (2 Side)
  • Number of Positions:7
  • Positions Per Level:7
  • Number of Levels:1
  • Pitch:0.200" (5.08mm)
  • Header Orientation:90°, Right Angle
  • Plug Wire Entry:-
  • Termination Style:Solder
  • Mounting Type:Through Hole
  • Current - IEC:18A
  • Voltage - IEC:400 V
  • Current - UL:15 A
  • Voltage - UL:300 V
  • Wire Gauge or Range - AWG:-
  • Wire Gauge or Range - mm²:-
  • Color:Orange
  • Operating Temperature:-50°C ~ 100°C
  • Contact Mating Finish:Tin
  • Features:-
