2-320572-2

Image is for reference, please contact us to get the real picture

Manufacturer Part
2-320572-2
Manufacturer
TE Connectivity AMP Connectors
Description
CONN RING CIRC 22AWG #5/16 CRIMP
Category
Connectors, Interconnects
Family
Terminals - Ring Connectors
Series
-
In Stock
3383
Datasheets
-

2-320572-2 Specifications

  • Series:PIDG
  • Package:Bulk
  • Part Status:Active
  • Terminal Type:Circular
  • Stud/Tab Size:5/16 Stud
  • Thickness:0.031" (0.79mm)
  • Width - Outer Edges:0.469" (11.91mm)
  • Length - Overall:1.140" (28.96mm)
  • Mounting Type:Free Hanging (In-Line)
  • Termination:Crimp
  • Wire Gauge:22 AWG
  • Insulation:Insulated
  • Features:Insulation Restriction
  • Color:Red, Green Stripe
  • Contact Material:Copper
  • Contact Finish:Tin
