SFV28R-1STE1HLF Specifications

• Series:SFV-R
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Flat Flex Type:FFC, FPC
• Mounting Type:Surface Mount, Right Angle
• Connector/Contact Type:Contacts, Bottom
• Number of Positions:28
• Pitch:0.020" (0.50mm)
• Termination:Solder
• FFC, FCB Thickness:0.33mm
• Height Above Board:0.071" (1.80mm)
• Locking Feature:Slide Lock
• Cable End Type:Notched
• Contact Material:Phosphor Bronze
• Contact Finish:Tin
• Housing Material:Liquid Crystal Polymer (LCP), Glass Filled, Halogen Free
• Actuator Material:Polyphenylene Sulfide (PPS), Glass Filled, Halogen Free
• Features:Zero Insertion Force (ZIF)
• Voltage Rating:50V
• Operating Temperature:-55°C ~ 105°C
• Material Flammability Rating:UL94 V-0
