14-823-90

Image is for reference, please contact us to get the real picture

Manufacturer Part
14-823-90
Manufacturer
Aries Electronics, Inc.
Description
CONN IC DIP SOCKET 14POS GOLD
Category
Connectors, Interconnects
Family
Sockets for ICs, Transistors
Series
-
In Stock
181
Datasheets
-

14-823-90 Specifications

  • Series:Vertisockets™ 800
  • Package:Bulk
  • Part Status:Active
  • Type:DIP, 0.3" (7.62mm) Row Spacing
  • Number of Positions or Pins (Grid):14 (2 x 7)
  • Pitch - Mating:0.100" (2.54mm)
  • Contact Finish - Mating:Gold
  • Contact Finish Thickness - Mating:10.0µin (0.25µm)
  • Contact Material - Mating:Phosphor Bronze
  • Mounting Type:Through Hole, Right Angle, Horizontal
  • Features:Closed Frame
  • Termination:Solder
  • Pitch - Post:0.100" (2.54mm)
  • Contact Finish - Post:Gold
  • Contact Finish Thickness - Post:10.0µin (0.25µm)
  • Contact Material - Post:Phosphor Bronze
  • Housing Material:Polyamide (PA46), Nylon 4/6
  • Operating Temperature:-
