AE770W24-19SW

Image is for reference, please contact us to get the real picture

Manufacturer Part
AE770W24-19SW
Manufacturer
PEI-Genesis
Description
CONN RCPT FMALE 19POS CRIMP
Category
Connectors, Interconnects
Family
Circular Connectors
Series
-
In Stock
44
Datasheets
-

AE770W24-19SW Specifications

  • Series:MIL-DTL-26482 Series II
  • Package:Box
  • Part Status:Active
  • Connector Type:Receptacle, Female Socket
  • Number of Positions:19
  • Shell Size - Insert:24-19
  • Shell Size, MIL:-
  • Mounting Type:Panel Mount
  • Mounting Feature:Flange
  • Termination:Crimp
  • Fastening Type:Bayonet Lock
  • Orientation:W
  • Shell Material:Aluminum
  • Shell Finish:Olive Drab Cadmium
  • Contact Finish - Mating:Gold
  • Color:Olive Drab
  • Ingress Protection:IP67 - Dust Tight, Waterproof
  • Material Flammability Rating:-
  • Features:-
  • Shielding:Shielded
  • Current Rating (Amps):23A
  • Voltage Rating:1000VDC
  • Cable Opening:-
  • Operating Temperature:-55°C ~ 175°C
