8282-5SG-318

Image is for reference, please contact us to get the real picture

Manufacturer Part
8282-5SG-318
Manufacturer
Switchcraft / Conxall
Description
CONN RCPT FMALE 5P GOLD SLDR CUP
Category
Connectors, Interconnects
Family
Circular Connectors
Series
-
In Stock
22
Datasheets
-

8282-5SG-318 Specifications

  • Series:Mini-Con-X®
  • Package:Bulk
  • Part Status:Active
  • Connector Type:Receptacle, Female Sockets
  • Number of Positions:5
  • Shell Size - Insert:-
  • Shell Size, MIL:-
  • Mounting Type:Free Hanging (In-Line)
  • Mounting Feature:-
  • Termination:Solder Cup
  • Fastening Type:Bayonet Lock
  • Orientation:Keyed
  • Shell Material:Polyamide (PA), Nylon
  • Shell Finish:-
  • Contact Finish - Mating:Gold
  • Color:Black
  • Ingress Protection:Weathertight
  • Material Flammability Rating:-
  • Features:Backshell
  • Shielding:Unshielded
  • Current Rating (Amps):5.6A
  • Voltage Rating:600V
  • Cable Opening:0.180" ~ 0.200" (4.57mm ~ 5.08mm)
  • Operating Temperature:-40°C ~ 115°C
