JN2DW05MH3

Image is for reference, please contact us to get the real picture

Manufacturer Part
JN2DW05MH3
Manufacturer
JAE Electronics
Description
CONN PLUG MALE 5P SOLDER CUP
Category
Connectors, Interconnects
Family
Circular Connectors
Series
-
In Stock
36
Datasheets
-

JN2DW05MH3 Specifications

  • Series:JN2W
  • Package:Bulk
  • Part Status:Active
  • Connector Type:Plug, Male Pins
  • Number of Positions:5 (4 Power + PE)
  • Shell Size - Insert:W
  • Shell Size, MIL:-
  • Mounting Type:Free Hanging (In-Line)
  • Mounting Feature:-
  • Termination:Solder Cup
  • Fastening Type:Push-Twist
  • Orientation:N (Normal)
  • Shell Material:Zinc Alloy
  • Shell Finish:Zinc
  • Contact Finish - Mating:Silver
  • Color:Black
  • Ingress Protection:IP67 - Dust Tight, Waterproof
  • Material Flammability Rating:-
  • Features:Backshell, Coupling Nut
  • Shielding:-
  • Current Rating (Amps):13A
  • Voltage Rating:400VAC
  • Cable Opening:-
  • Operating Temperature:-20°C ~ 100°C
