09695015247

Image is for reference, please contact us to get the real picture

Manufacturer Part
09695015247
Manufacturer
HARTING
Description
CONN D-SUB RCPT 24POS SLDR CUP
Category
Connectors, Interconnects
Family
D-Sub Connectors
Series
-
In Stock
37
Datasheets
-

09695015247 Specifications

  • Series:-
  • Package:Bulk
  • Part Status:Active
  • Connector Style:D-Sub, Combo
  • Connector Type:Receptacle, Female Sockets
  • Number of Positions:24 (17 + 7 Coax or Power)
  • Number of Rows:2
  • Mounting Type:Free Hanging (In-Line)
  • Shell Size, Connector Layout:5 (DD, D) - 24W7
  • Contact Type:Signal and Coax or Power (Not Included)
  • Flange Feature:Housing/Shell (Unthreaded)
  • Termination:Solder Cup
  • Shell Material, Finish:Steel, Tin Plated
  • Contact Finish:Gold or Gold-Palladium
  • Contact Finish Thickness:30.0µin (0.76µm)
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Current Rating (Amps):5A
  • Backset Spacing:-
  • Features:-
