09562525613

Image is for reference, please contact us to get the real picture

Manufacturer Part
09562525613
Manufacturer
HARTING
Description
CONN D-SUB HD RCPT 26P R/A SLDR
Category
Connectors, Interconnects
Family
D-Sub Connectors
Series
-
In Stock
226
Datasheets
-

09562525613 Specifications

  • Series:-
  • Package:Tray
  • Part Status:Active
  • Connector Style:D-Sub, High Density
  • Connector Type:Receptacle, Female Sockets
  • Number of Positions:26
  • Number of Rows:3
  • Mounting Type:Through Hole, Right Angle
  • Shell Size, Connector Layout:2 (DA, A) High Density
  • Contact Type:Signal
  • Flange Feature:Mating Side, Female Screwlock (4-40)
  • Termination:Solder
  • Shell Material, Finish:Steel, Nickel Plated
  • Contact Finish:Gold or Gold-Palladium
  • Contact Finish Thickness:30.0µin (0.76µm)
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Current Rating (Amps):2A
  • Backset Spacing:0.350" (8.89mm)
  • Features:Board Lock
