CZ3A02

Image is for reference, please contact us to get the real picture

Manufacturer Part
CZ3A02
Manufacturer
Asahi Kasei Microdevices / AKM Semiconductor
Description
3.3V OUTPUT ACCURATE CORELESS CU
Category
Sensors, Transducers
Family
Current Sensors
Series
-
In Stock
1000
Datasheets
-

CZ3A02 Specifications

  • Series:CZ
  • Package:Tape & Reel (TR)Cut Tape (CT)
  • Part Status:Active
  • For Measuring:AC/DC
  • Sensor Type:Hall Effect, Open Loop
  • Current - Sensing:15.5A
  • Number of Channels:1
  • Output:Voltage
  • Sensitivity:100mV/A
  • Frequency:-
  • Linearity:±0.6%
  • Accuracy:±2.1%
  • Voltage - Supply:3V ~ 3.6V
  • Response Time:1µs
  • Current - Supply (Max):16mA (Typ)
  • Operating Temperature:-40°C ~ 85°C (TA)
  • Polarization:Unidirectional
  • Mounting Type:Surface Mount
  • Package / Case:16-PowerSOIC (0.303", 7.70mm Width), 10 Leads
  • Supplier Device Package:-
