TPS7A6350QPWPRQ1 Specifications

• Series:Automotive, AEC-Q100
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Output Configuration:Positive
• Output Type:Fixed
• Number of Regulators:1
• Voltage - Input (Max):40V
• Voltage - Output (Min/Fixed):5V
• Voltage - Output (Max):-
• Voltage Dropout (Max):0.5V @ 200mA
• Current - Output:200mA
• Current - Quiescent (Iq):35 µA
• Current - Supply (Max):-
• PSRR:60dB ~ 30dB (100Hz ~ 150kHz)
• Control Features:Enable, Reset
• Protection Features:Over Current, Over Temperature, Short Circuit, Under Voltage Lockout (UVLO), Watchdog
• Operating Temperature:-40°C ~ 150°C
• Mounting Type:Surface Mount
• Package / Case:14-PowerTSSOP (0.173", 4.40mm Width)
• Supplier Device Package:14-HTSSOP
