MCP1825T-1202E/ET Specifications

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Output Configuration:Positive
• Output Type:Fixed
• Number of Regulators:1
• Voltage - Input (Max):6V
• Voltage - Output (Min/Fixed):1.2V
• Voltage - Output (Max):-
• Voltage Dropout (Max):0.35V @ 500mA
• Current - Output:500mA
• Current - Quiescent (Iq):220 µA
• Current - Supply (Max):-
• PSRR:60dB (100Hz)
• Control Features:Enable, Power Good
• Protection Features:Over Temperature, Short Circuit, Under Voltage Lockout (UVLO)
• Operating Temperature:-40°C ~ 125°C
• Mounting Type:Surface Mount
• Package / Case:TO-263-6, D²Pak (5 Leads + Tab), TO-263BA
• Supplier Device Package:5-DDPAK
