AP7176BSP-13 Specifications

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Output Configuration:Positive
• Output Type:Adjustable
• Number of Regulators:1
• Voltage - Input (Max):3.65V
• Voltage - Output (Min/Fixed):0.8V
• Voltage - Output (Max):3.12V
• Voltage Dropout (Max):0.53V @ 3A
• Current - Output:3A
• Current - Quiescent (Iq):1.5 mA
• Current - Supply (Max):-
• PSRR:-
• Control Features:Enable, Power Good
• Protection Features:Over Current, Over Temperature, Power On Reset (POR), Short Circuit, Soft Start
• Operating Temperature:-40°C ~ 85°C
• Mounting Type:Surface Mount
• Package / Case:8-SOIC (0.154", 3.90mm Width) Exposed Pad
• Supplier Device Package:8-SO-EP
