ADG201HSJP Specifications

• Series:-
• Package:Tube
• Part Status:Obsolete
• Switch Circuit:SPST - NC
• Multiplexer/Demultiplexer Circuit:1:1
• Number of Circuits:4
• On-State Resistance (Max):50Ohm
• Channel-to-Channel Matching (ΔRon):1.5Ohm
• Voltage - Supply, Single (V+):10.8V ~ 16.5V
• Voltage - Supply, Dual (V±):±13.5V ~ 16.5V
• Switch Time (Ton, Toff) (Max):75ns, 75ns
• -3db Bandwidth:-
• Charge Injection:10pC
• Channel Capacitance (CS(off), CD(off)):10pF, 10pF
• Current - Leakage (IS(off)) (Max):1nA
• Crosstalk:-86dB @ 100kHz
• Operating Temperature:-40°C ~ 85°C (TA)
• Mounting Type:Surface Mount
• Package / Case:20-LCC (J-Lead)
• Supplier Device Package:20-PLCC (9x9)
