TS5A23166DCUR Specifications

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Switch Circuit:SPST - NO
• Multiplexer/Demultiplexer Circuit:1:1
• Number of Circuits:2
• On-State Resistance (Max):900mOhm
• Channel-to-Channel Matching (ΔRon):40mOhm
• Voltage - Supply, Single (V+):1.65V ~ 5.5V
• Voltage - Supply, Dual (V±):-
• Switch Time (Ton, Toff) (Max):7.5ns, 11ns
• -3db Bandwidth:150MHz
• Charge Injection:6pC
• Channel Capacitance (CS(off), CD(off)):19pF, 18pF
• Current - Leakage (IS(off)) (Max):20nA
• Crosstalk:-85dB @ 1MHz
• Operating Temperature:-40°C ~ 85°C (TA)
• Mounting Type:Surface Mount
• Package / Case:8-VFSOP (0.091", 2.30mm Width)
• Supplier Device Package:8-VSSOP
