MAX4729EXT+T Specifications

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Switch Circuit:SPDT
• Multiplexer/Demultiplexer Circuit:2:1
• Number of Circuits:1
• On-State Resistance (Max):5.5Ohm
• Channel-to-Channel Matching (ΔRon):50mOhm
• Voltage - Supply, Single (V+):1.8V ~ 5.5V
• Voltage - Supply, Dual (V±):-
• Switch Time (Ton, Toff) (Max):45ns, 26ns
• -3db Bandwidth:300MHz
• Charge Injection:3pC
• Channel Capacitance (CS(off), CD(off)):6.5pF
• Current - Leakage (IS(off)) (Max):2nA
• Crosstalk:-67dB @ 1MHz
• Operating Temperature:-40°C ~ 85°C (TA)
• Mounting Type:Surface Mount
• Package / Case:6-TSSOP, SC-88, SOT-363
• Supplier Device Package:SC-70-6
