DG2502DB-T2-GE1 Specifications

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Switch Circuit:SPST - NO
• Multiplexer/Demultiplexer Circuit:1:1
• Number of Circuits:4
• On-State Resistance (Max):8Ohm
• Channel-to-Channel Matching (ΔRon):-
• Voltage - Supply, Single (V+):1.8V ~ 5.5V
• Voltage - Supply, Dual (V±):-
• Switch Time (Ton, Toff) (Max):100ns, 60ns
• -3db Bandwidth:550MHz
• Charge Injection:-2pC
• Channel Capacitance (CS(off), CD(off)):2.9pF, 2.8pF
• Current - Leakage (IS(off)) (Max):400pA
• Crosstalk:-83dB @ 1MHz
• Operating Temperature:-40°C ~ 85°C (TA)
• Mounting Type:Surface Mount
• Package / Case:16-XFBGA, WLCSP
• Supplier Device Package:16-WCSP (1.44x1.44)
