DG1409EEN-T1-GE4 Specifications

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Switch Circuit:-
• Multiplexer/Demultiplexer Circuit:4:2
• Number of Circuits:2
• On-State Resistance (Max):4.2Ohm
• Channel-to-Channel Matching (ΔRon):270mOhm
• Voltage - Supply, Single (V+):4.5V ~ 24V
• Voltage - Supply, Dual (V±):±4.5V ~ 16.5V
• Switch Time (Ton, Toff) (Max):130ns, 105ns
• -3db Bandwidth:90MHz
• Charge Injection:103pC
• Channel Capacitance (CS(off), CD(off)):13pF, 43pF
• Current - Leakage (IS(off)) (Max):550pA
• Crosstalk:-64dB @ 1MHz
• Operating Temperature:-40°C ~ 125°C (TA)
• Mounting Type:Surface Mount
• Package / Case:16-VQFN Exposed Pad
• Supplier Device Package:16-QFN (4x4)
