DG412HSDN-T1-E4 Specifications

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Switch Circuit:SPST - NO
• Multiplexer/Demultiplexer Circuit:1:1
• Number of Circuits:4
• On-State Resistance (Max):35Ohm
• Channel-to-Channel Matching (ΔRon):-
• Voltage - Supply, Single (V+):12V
• Voltage - Supply, Dual (V±):±5V ~ 20V
• Switch Time (Ton, Toff) (Max):105ns, 80ns
• -3db Bandwidth:-
• Charge Injection:22pC
• Channel Capacitance (CS(off), CD(off)):12pF, 12pF
• Current - Leakage (IS(off)) (Max):250pA
• Crosstalk:-88dB @ 1MHz
• Operating Temperature:-40°C ~ 85°C (TA)
• Mounting Type:Surface Mount
• Package / Case:16-VQFN Exposed Pad
• Supplier Device Package:16-QFN (4x4)
