ADG904BCPZ-REEL7 Specifications

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Switch Circuit:SP4T
• Multiplexer/Demultiplexer Circuit:4:1
• Number of Circuits:1
• On-State Resistance (Max):-
• Channel-to-Channel Matching (ΔRon):-
• Voltage - Supply, Single (V+):1.65V ~ 2.75V
• Voltage - Supply, Dual (V±):-
• Switch Time (Ton, Toff) (Max):10ns, 16ns
• -3db Bandwidth:2.5GHz
• Charge Injection:-
• Channel Capacitance (CS(off), CD(off)):2pF
• Current - Leakage (IS(off)) (Max):1µA
• Crosstalk:-58dB @ 100MHz
• Operating Temperature:-40°C ~ 85°C (TA)
• Mounting Type:Surface Mount
• Package / Case:20-WFQFN Exposed Pad, CSP
• Supplier Device Package:20-LFCSP-WQ (4x4)
