NLAS5223BMNR2G Specifications

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Switch Circuit:SPDT
• Multiplexer/Demultiplexer Circuit:2:1
• Number of Circuits:2
• On-State Resistance (Max):350mOhm
• Channel-to-Channel Matching (ΔRon):50mOhm (Max)
• Voltage - Supply, Single (V+):1.65V ~ 4.5V
• Voltage - Supply, Dual (V±):-
• Switch Time (Ton, Toff) (Max):50ns, 50ns
• -3db Bandwidth:19MHz
• Charge Injection:38pC
• Channel Capacitance (CS(off), CD(off)):60pF
• Current - Leakage (IS(off)) (Max):500nA
• Crosstalk:-70dB @ 100kHz
• Operating Temperature:-40°C ~ 85°C (TA)
• Mounting Type:Surface Mount
• Package / Case:10-WFQFN
• Supplier Device Package:10-WQFN (1.4x1.8)
