NLVASB3157DFT2G Specifications

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Switch Circuit:SPDT
• Multiplexer/Demultiplexer Circuit:2:1
• Number of Circuits:1
• On-State Resistance (Max):7Ohm (Typ)
• Channel-to-Channel Matching (ΔRon):500mOhm
• Voltage - Supply, Single (V+):1.65V ~ 5.5V
• Voltage - Supply, Dual (V±):-
• Switch Time (Ton, Toff) (Max):-
• -3db Bandwidth:250MHz
• Charge Injection:7pC
• Channel Capacitance (CS(off), CD(off)):-
• Current - Leakage (IS(off)) (Max):100nA
• Crosstalk:-54dB @ 10MHz
• Operating Temperature:-55°C ~ 125°C (TA)
• Mounting Type:Surface Mount
• Package / Case:6-TSSOP, SC-88, SOT-363
• Supplier Device Package:SC-88/SC70-6/SOT-363
