MA950.W.A.LBICG.005 Specifications

• Series:Guardian
• Package:Box
• Part Status:Active
• RF Family/Standard:Cellular, Navigation, WiFi
• Frequency Group:Wide Band
• Frequency (Center/Band):750.5MHz, 859MHz, 920MHz, 1.574GHz, 1.795GHz, 1.92GHz, 2.045GHz, 2.3325GHz, 2.45GHz, 2.59GHz, 3.45GHz, 5.375GHz
• Frequency Range:698MHz ~ 960MHz, 1.559GHz ~ 1.575GHz, 1.597GHz ~ 1.607GHz, 1.71GHz ~ 2.69GHz, 3.3GHz ~ 3.6GHz, 4.9GHz ~ 5.85GHz
• Antenna Type:Module
• Number of Bands:15
• VSWR:2, 3
• Return Loss:10dB
• Gain:3.18dBi, 3.6dBi, 2.14dBi, 3dBi, 1.98dBi, 3.01dBi, 3.98dBi, 4.37dBi, 4.37dBi, 4.35dBi, 3.7dBi, 4.49dBi, 4.84dBi
• Power - Max:-
• Features:Cable - 1m, LNA, Filter
• Termination:SMA Male
• Ingress Protection:IP67
• Mounting Type:Adhesive
• Height (Max):0.787" (20.00mm)
• Applications:2G, 3G, 4G, Beidou, Galileo, GLONASS, GNSS, GPS, LTE, Wi-Fi
