MA841.A.BI.002 Specifications

• Series:-
• Package:Box
• Part Status:Active
• RF Family/Standard:Cellular
• Frequency Group:Wide Band
• Frequency (Center/Band):750.5MHz, 859MHz, 920MHz, 1.795GHz, 1.92GHz, 2.045GHz, 2.59GHz
• Frequency Range:698MHz ~ 803MHz, 824MHz ~ 894MHz, 880MHz ~ 960MHz, 1.71GHz ~ 1.88GHz, 1.85GHz ~ 1.99GHz, 1.92GHz ~ 2.17GHz, 2.49GHz ~ 2.69GHz
• Antenna Type:Dome
• Number of Bands:7
• VSWR:3.5
• Return Loss:-
• Gain:1.51dBi, 3.56dBi, 2.09dBi, 1.95dBi, 2.72dBi, 1.95dBi, 1.98dBi, 2.37dBi, 1.32dBi, 1.79dBi, 1.04dBi, 2.36dBi, 5.91dBi, 4.99dBi
• Power - Max:-
• Features:Cable - 1m
• Termination:SMA Male
• Ingress Protection:IP67
• Mounting Type:Panel Mount
• Height (Max):2.260" (57.40mm)
• Applications:2G, 3G, 4G, LTE
