FMA103.A.AF.001 Specifications

• Series:-
• Package:Bag
• Part Status:Active
• RF Family/Standard:Navigation
• Frequency Group:Wide Band
• Frequency (Center/Band):860MHz, 920MHz, 1.575GHz, 1.795GHz, 1.92GHz, 2.045GHz
• Frequency Range:824MHz ~ 896MHz, 880MHz ~ 960MHz, 1.574GHz ~ 1.576GHz, 1.71GHz ~ 1.88GHz, 1.85GHz ~ 1.99GHz, 1.92GHz ~ 2.17GHz
• Antenna Type:Dome
• Number of Bands:6
• VSWR:2, 3.5
• Return Loss:-13dB, -11dB, -21dB, -21dB, -19dB
• Gain:0.1dBi, 1.6dBi, -1dBi, 0.1dBi, 0.6dBi, -0.9dBi
• Power - Max:10 W
• Features:Cable - 3m, LNA
• Termination:SMA Male
• Ingress Protection:IP67, IP69K
• Mounting Type:Panel Mount
• Height (Max):1.142" (29.00mm)
• Applications:GLONASS, GPS
