VFD69383W1NJN-518Q Specifications

• Series:-
• Package:Bulk
• Part Status:Active
• RF Family/Standard:Cellular, General ISM, Navigation
• Frequency Group:Wide Band
• Frequency (Center/Band):752MHz, 859MHz, 920MHz, 1.561GHz, 1.575GHz, 1.602GHz, 1.785GHz, 1.92GHz, 2.045GHz, 2.4GHz, 2.6GHz, 3.55GHz
• Frequency Range:698MHz ~ 806MHz, 824MHz ~ 894MHz, 880MHz ~ 960MHz, 1.559GHz ~ 1.606GHz, 1.69GHz ~ 1.88GHz, 1.85GHz ~ 1.99GHz, 1.91GHz ~ 2.18GHz, 2.3GHz ~ 2.5GHz, 2.5GHz ~ 2.7GHz, 3.3GHz ~ 3.8GHz
• Antenna Type:Dome
• Number of Bands:12
• VSWR:2
• Return Loss:-
• Gain:0.9dBi, 1.7dBi, 1.9dBi, 3.7dBi, 4.7dBi, 5.6dBi, 4.3dBi, 3.8dBi, 3.8dBi, 5.1dBi, 5.5dBi, 7dBi
• Power - Max:10 W
• Features:Cable - 5.18m, LNA
• Termination:SMA Male (2)
• Ingress Protection:IP67
• Mounting Type:Panel Mount
• Height (Max):1.890" (48.00mm)
• Applications:3G, 4G, 5G, Beidou, GLONASS, GNSS, GPS, ISM, LTE
