TG.45.8113 Specifications

• Series:-
• Package:Bag
• Part Status:Active
• RF Family/Standard:Cellular, Navigation
• Frequency Group:Wide Band
• Frequency (Center/Band):460MHz, 752MHz, 753MHz, 859MHz, 920MHz, 1.5815GHz, 1.795GHz, 1.92GHz, 2.045GHz, 2.3325GHz, 2.495GHz, 3.5GHz, 5.375GHz
• Frequency Range:450MHz ~ 470MHz, 698MHz ~ 960MHz, 1.561GHz ~ 1.602GHz, 1.71GHz ~ 2.69GHz, 3.4GHz ~ 3.6GHz, 4.9GHz ~ 5.85GHz
• Antenna Type:Whip, Straight
• Number of Bands:13
• VSWR:-
• Return Loss:-
• Gain:1.46dBi, 2.87dBi, 2.87dBi, 3.26dBi, 3.58dBi, 0.75dBi, 3.95dBi, 4.17dBi, 4.85dBi, 2.82dBi, 4.16dBi, 0.26dBi, 3.88dBi
• Power - Max:5 W
• Features:-
• Termination:SMA Male
• Ingress Protection:-
• Mounting Type:Connector Mount
• Height (Max):8.583" (218.00mm)
• Applications:Beidou, CDMA, DCS, EDGE, Galileo, GLONASS, GPRS, GPS, HSPA, LTE, PCS, UMTS, WCDMA
