G45.A.201111 Specifications

• Series:Olympian II
• Package:Bag
• Part Status:Active
• RF Family/Standard:Cellular
• Frequency Group:Wide Band
• Frequency (Center/Band):657.5MHz, 752MHz, 892MHz, 1.4725GHz, 1.955GHz, 2.495GHz, 3.75GHz
• Frequency Range:617MHz ~ 698MHz, 698MHz ~ 806MHz, 824MHz ~ 960MHz, 1.427GHz ~ 1.518GHz, 1.71GHz ~ 2.2GHz, 2.3GHz ~ 2.69GHz, 3.3GHz ~ 4.2GHz
• Antenna Type:Dome
• Number of Bands:7
• VSWR:-
• Return Loss:-
• Gain:1.3dBi, 0.6dBi, 1.4dBi, -0.8dBi, 1.5dBi, 1dBi, -1.3dBi
• Power - Max:2 W
• Features:Cable - 2m
• Termination:SMA Male
• Ingress Protection:IP67
• Mounting Type:Panel Mount
• Height (Max):1.909" (48.50mm)
• Applications:3G, 4G, 5G, HSPA, HSPA+, LTE, WCDMA
