CFSA69383P1-30NF Specifications

• Series:-
• Package:Bulk
• Part Status:Active
• RF Family/Standard:Cellular, WiFi
• Frequency Group:Wide Band
• Frequency (Center/Band):752MHz, 859MHz, 920MHz, 1.45GHz, 1.785GHz, 1.92GHz, 2.045GHz, 2.4GHz, 2.6GHz, 3.55GHz, 3.9GHz
• Frequency Range:698MHz ~ 960MHz, 1.35GHz ~ 1.55GHz, 1.69GHz ~ 4GHz
• Antenna Type:Flat Panel
• Number of Bands:11
• VSWR:1.5, 1.8, 2
• Return Loss:-
• Gain:3.2dBi, 2.6dBi, 3.4dBi, 4.2dBi, 4dBi, 4.4dBi, 4.2dBi, 4.3dBi, 5.4dBi, 2.4dBi, 3dBi
• Power - Max:50 W
• Features:Cable - 300mm
• Termination:N Type Female
• Ingress Protection:-
• Mounting Type:Panel Mount
• Height (Max):0.300" (7.62mm)
• Applications:AWS, GSM, DCS, LTE, UMTS, WiMax™
