H11AV1VM Specifications

• Series:-
• Package:Bulk
• Part Status:Active
• Number of Channels:1
• Voltage - Isolation:4170Vrms
• Current Transfer Ratio (Min):100% @ 10mA
• Current Transfer Ratio (Max):300% @ 10mA
• Turn On / Turn Off Time (Typ):15µs, 15µs (Max)
• Rise / Fall Time (Typ):-
• Input Type:DC
• Output Type:Transistor with Base
• Voltage - Output (Max):70V
• Current - Output / Channel:-
• Voltage - Forward (Vf) (Typ):1.18V
• Current - DC Forward (If) (Max):60 mA
• Vce Saturation (Max):400mV
• Operating Temperature:-40°C ~ 100°C
• Mounting Type:Through Hole
• Package / Case:6-DIP (0.300", 7.62mm)
• Supplier Device Package:6-DIP
