HCPL0731 Specifications

• Series:-
• Package:Tube
• Part Status:Active
• Number of Channels:2
• Voltage - Isolation:2500Vrms
• Current Transfer Ratio (Min):400% @ 500µA
• Current Transfer Ratio (Max):5000% @ 500µA
• Turn On / Turn Off Time (Typ):300ns, 1.6µs
• Rise / Fall Time (Typ):-
• Input Type:DC
• Output Type:Darlington
• Voltage - Output (Max):18V
• Current - Output / Channel:60mA
• Voltage - Forward (Vf) (Typ):1.35V
• Current - DC Forward (If) (Max):20 mA
• Vce Saturation (Max):-
• Operating Temperature:-40°C ~ 85°C
• Mounting Type:Surface Mount
• Package / Case:8-SOIC (0.154", 3.90mm Width)
• Supplier Device Package:8-SOIC
