RV1S2285ACCSP-10YV#SC0

Image is for reference, please contact us to get the real picture

Manufacturer Part
RV1S2285ACCSP-10YV#SC0
Manufacturer
Renesas Electronics America
Description
OPTO COUPLER IN 4PIN SSOP
Category
Isolators
Family
Optoisolators - Transistor, Photovoltaic Output
Series
-
In Stock
30
Datasheets
-

RV1S2285ACCSP-10YV#SC0 Specifications

  • Series:-
  • Package:Strip
  • Part Status:Active
  • Number of Channels:1
  • Voltage - Isolation:5000Vrms
  • Current Transfer Ratio (Min):50% @ 5mA
  • Current Transfer Ratio (Max):400% @ 5mA
  • Turn On / Turn Off Time (Typ):-
  • Rise / Fall Time (Typ):4µs, 5µs
  • Input Type:AC, DC
  • Output Type:Transistor
  • Voltage - Output (Max):80V
  • Current - Output / Channel:30mA
  • Voltage - Forward (Vf) (Typ):1.15V
  • Current - DC Forward (If) (Max):30 mA
  • Vce Saturation (Max):300mV
  • Operating Temperature:-40°C ~ 115°C
  • Mounting Type:Surface Mount
  • Package / Case:4-SOP (0.295", 7.50mm Width)
  • Supplier Device Package:4-LSSOP
