B82422A3681J100

Image is for reference, please contact us to get the real picture

Manufacturer Part
B82422A3681J100
Manufacturer
TDK EPCOS
Description
FIXED IND 680NH 145MA 2.4 OHM
Category
Inductors, Coils, Chokes
Family
Fixed Inductors
Series
-
In Stock
0
Datasheets
-

B82422A3681J100 Specifications

  • Series:SIMID
  • Package:Tape & Reel (TR)
  • Part Status:Active
  • Type:Wirewound
  • Material - Core:Ceramic
  • Inductance:680 nH
  • Tolerance:±5%
  • Current Rating (Amps):145 mA
  • Current - Saturation (Isat):-
  • Shielding:Unshielded
  • DC Resistance (DCR):2.4Ohm Max
  • Q @ Freq:22 @ 30MHz
  • Frequency - Self Resonant:280MHz
  • Ratings:AEC-Q200
  • Operating Temperature:-55°C ~ 125°C
  • Inductance Frequency - Test:1 MHz
  • Features:-
  • Mounting Type:Surface Mount
  • Package / Case:2-SMD, J-Lead
  • Supplier Device Package:1210 (3225 Metric)
  • Size / Dimension:0.126" L x 0.098" W (3.20mm x 2.50mm)
  • Height - Seated (Max):0.083" (2.10mm)
