P0174NL

Image is for reference, please contact us to get the real picture

Manufacturer Part
P0174NL
Manufacturer
PulseLarsen Antenna
Description
INDUCT ARRAY 2 COIL 2.2UH SMD
Category
Inductors, Coils, Chokes
Family
Arrays, Signal Transformers
Series
-
In Stock
0
Datasheets
-

P0174NL Specifications

  • Series:Polecat
  • Package:Tube
  • Part Status:Active
  • Number of Coils:2
  • Inductance - Connected In Parallel:2.2 µH
  • Inductance - Connected In Series:8.75 µH
  • Tolerance:±10%
  • Current Rating - Parallel:8.3 A
  • Current Rating - Series:4.16 A
  • Current Saturation - Parallel:-
  • Current Saturation - Series:-
  • DC Resistance (DCR) - Parallel:7.6mOhm Max
  • DC Resistance (DCR) - Series:32mOhm Max
  • Shielding:Unshielded
  • Ratings:-
  • Operating Temperature:-40°C ~ 130°C
  • Mounting Type:Surface Mount
  • Package / Case:Nonstandard
  • Size / Dimension:0.500" L x 0.500" W (12.70mm x 12.70mm)
  • Height:0.215" (5.46mm)
