PA0766.421NLT

Image is for reference, please contact us to get the real picture

Manufacturer Part
PA0766.421NLT
Manufacturer
PulseLarsen Antenna
Description
INDUCT ARRAY 2 COIL 218NH SMD
Category
Inductors, Coils, Chokes
Family
Arrays, Signal Transformers
Series
-
In Stock
0
Datasheets
-

PA0766.421NLT Specifications

  • Series:PA0766NL
  • Package:Tape & Reel (TR)
  • Part Status:Active
  • Number of Coils:2
  • Inductance - Connected In Parallel:218 nH
  • Inductance - Connected In Series:870 nH
  • Tolerance:±20%
  • Current Rating - Parallel:50 A
  • Current Rating - Series:25 A
  • Current Saturation - Parallel:50 A
  • Current Saturation - Series:25 A
  • DC Resistance (DCR) - Parallel:0.38mOhm Max
  • DC Resistance (DCR) - Series:1.5mOhm Max
  • Shielding:Unshielded
  • Ratings:-
  • Operating Temperature:-40°C ~ 130°C
  • Mounting Type:Surface Mount
  • Package / Case:Nonstandard
  • Size / Dimension:0.551" L x 0.531" W (14.00mm x 13.50mm)
  • Height:0.276" (7.00mm)
