B36H3RGB-F6C0001HOU1930

Image is for reference, please contact us to get the real picture

Manufacturer Part
B36H3RGB-F6C0001HOU1930
Manufacturer
Harvatek Corporation
Description
LED RGB COMMON ANODE (0.69 (L)X
Category
Optoelectronics
Family
LED Indication - Discrete
Series
-
In Stock
0
Datasheets
-

B36H3RGB-F6C0001HOU1930 Specifications

  • Series:-
  • Package:Tape & Reel (TR)Cut Tape (CT)
  • Part Status:Active
  • Color:Red, Green, Blue (RGB)
  • Configuration:Common Anode
  • Lens Color:-
  • Lens Transparency:-
  • Millicandela Rating:32mcd Red, 46mcd Green, 8mcd Blue
  • Lens Style:Square with Flat Top
  • Lens Size:0.69mm
  • Voltage - Forward (Vf) (Typ):1.9V Red, 2.5V Green, 2.5V Blue
  • Current - Test:5mA Red, 2mA Green, 2mA Blue
  • Viewing Angle:140°
  • Mounting Type:Surface Mount
  • Wavelength - Dominant:621nm Red, 530nm Green, 469nm Blue
  • Wavelength - Peak:628nm Red, 521nm Green, 465nm Blue
  • Features:-
  • Package / Case:4-SMD, No Lead
  • Supplier Device Package:Chip LED
  • Size / Dimension:0.69mm L x 0.69mm W
  • Height (Max):0.60mm
