SMI24-48-E-ST Specifications

• Series:SMI24 (24W)
• Package:Box
• Part Status:Active
• Region Utilized:Europe
• Form:Wall Mount (Class II)
• Input Type:Multi-Blade (Included)
• Voltage - Input:90 ~ 264 VAC
• Voltage - Output:48V
• Current - Output (Max):500mA
• Power (Watts):24 W
• No Load Power Consumption:100mW (Max)
• Polarization:-
• Applications:ITE (Commercial)
• Efficiency:Level VI, CoC Tier 2
• Operating Temperature:0°C ~ 40°C
• Output Connector:Stripped, Tinned Wire Leads
• Cord Length:59" (1.50m)
• Input Connector:Multi-Blade (Included)
• Size / Dimension:2.95" L x 1.41" W x 2.58" H (75.0mm x 35.8mm x 65.6mm)
• Approval Agency:CB Scheme, CCC, CSA, EN, IEC, PSE, RCM, UL
• Standard Number:C22.2 No. 60950-1; 55024; 55032 Class B; 60950-1; 61000-3-2; 61000-3-3; 62368-1
