SDI250-19-U-P219 Specifications

• Series:SDI250-U (250W)
• Package:Box
• Part Status:Active
• Region Utilized:International
• Form:Desktop (Class I)
• Input Type:Cord (Sold Separately)
• Voltage - Input:90 ~ 264 VAC
• Voltage - Output:19V
• Current - Output (Max):13.2A
• Power (Watts):251 W
• No Load Power Consumption:210mW (Max)
• Polarization:-
• Applications:ITE (Commercial)
• Efficiency:Level VI
• Operating Temperature:0°C ~ 40°C
• Output Connector:Rectangular, 6 Position
• Cord Length:47.2" (1.20m)
• Input Connector:IEC 320-C14
• Size / Dimension:8.03" L x 3.70" W x 1.71" H (204.0mm x 94.0mm x 43.5mm)
• Approval Agency:CB Scheme, CSA, EN, FCC, IEC, PSE, UL
• Standard Number:C22.2 No. 60950-1; 55024; 55032 Class B; 60950-1; 61000-3-2; 61000-3-3; 62368-1
