SDI200-48-U-P51 Specifications

• Series:SDI200-U (200W)
• Package:Box
• Part Status:Active
• Region Utilized:International
• Form:Desktop (Class I)
• Input Type:Cord (Sold Separately)
• Voltage - Input:90 ~ 264 VAC
• Voltage - Output:48V
• Current - Output (Max):4.17A
• Power (Watts):200 W
• No Load Power Consumption:150mW (Max)
• Polarization:-
• Applications:ITE (Commercial)
• Efficiency:Level VI, CoC Tier 2
• Operating Temperature:0°C ~ 40°C
• Output Connector:Power DIN, 4 Pin
• Cord Length:59" (1.50m)
• Input Connector:IEC 320-C14
• Size / Dimension:7.21" L x 3.19" W x 1.67" H (183.2mm x 81.0mm x 42.3mm)
• Approval Agency:CB Scheme, CSA, EN, FCC, IEC, PSE, UL
• Standard Number:C22.2 No. 60950-1; 55024; 55032 Class B; 60950-1; 61000-3-2; 61000-3-3; 62368-1
