JWT75525/R Specifications

• Series:JWT (75W)
• Package:Bulk
• Part Status:Not For New Designs
• Type:Open Frame
• Number of Outputs:3
• Voltage - Input:85 ~ 265 VAC
• Voltage - Output 1:5V
• Voltage - Output 2:12V
• Voltage - Output 3:-5V
• Voltage - Output 4:-
• Current - Output (Max):8A, 4A, 500mA
• Power (Watts):75W
• Applications:ITE (Commercial)
• Voltage - Isolation:3 kV
• Efficiency:72%
• Operating Temperature:-10°C ~ 65°C (With Derating)
• Features:Adjustable Output, DC Input Capable, PFC, Remote On/Off, Universal Input
• Mounting Type:Chassis Mount
• Size / Dimension:7.40" L x 3.62" W x 1.65" H (188.0mm x 92.0mm x 42.0mm)
• Approval Agency:CE
• Standard Number:-
