MEU-600C24T AAA Specifications

• Series:MEU-600C (600W)
• Package:Box
• Part Status:Active
• Type:Open Frame, Conformal Coated
• Number of Outputs:1
• Voltage - Input:85 ~ 264 VAC
• Voltage - Output 1:24V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):25A
• Power (Watts):600W
• Applications:ITE (Commercial), Medical
• Voltage - Isolation:4 kV
• Efficiency:93.5%
• Operating Temperature:-20°C ~ 70°C (With Derating)
• Features:Adjustable Output, PFC, PMBUS™, Remote On/Off, Standby Output, Universal Input
• Mounting Type:Chassis Mount
• Size / Dimension:8.00" L x 5.00" W x 1.57" H (203.2mm x 127.0mm x 40.0mm)
• Approval Agency:CB Scheme, CE, EN, SIQ, TUV, UL
• Standard Number:50581; 55011; 55032; 60601-1; 60950-1
