VGS-75D-15-B Specifications

• Series:VGS-75D
• Package:Box
• Part Status:Active
• Type:Enclosed, Conformal Coated
• Number of Outputs:1
• Voltage - Input:85 ~ 264 VAC, 120 ~ 370 VDC
• Voltage - Output 1:15V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):5A
• Power (Watts):75W
• Applications:Household Appliances, ITE (Commercial)
• Voltage - Isolation:4 kV
• Efficiency:86%
• Operating Temperature:-25°C ~ 70°C (With Derating)
• Features:Adjustable Output, DC Input Capable, PFC, Remote On/Off, Universal Input
• Mounting Type:Chassis Mount
• Size / Dimension:6.26" L x 3.82" W x 1.18" H (159.0mm x 97.0mm x 30.0mm)
• Approval Agency:CE, cUL, cURus, En, IEC, UL
• Standard Number:Class I; 55032 Class B; 60335; 61000-3-2; 61000-4-2; 61000-4-3; 61000-4-4; 61000-4-5; 61000-4-6; 61000-4-11; 61558; 62368
