TCP3500-1048G Specifications

• Series:TCP3500 (3500W)
• Package:Box
• Part Status:Active
• Type:Front End
• Number of Outputs:1
• Voltage - Input:180 ~ 528 VAC (3 Phase)
• Voltage - Output 1:48V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):73A
• Power (Watts):3500W
• Applications:ITE (Commercial)
• Voltage - Isolation:3 kV
• Efficiency:94%
• Operating Temperature:-40°C ~ 85°C
• Features:Adjustable Output, Baseplate, IP20, Load Sharing, PFC, Remote On/Off, Remote Sense, Universal Input
• Mounting Type:Rack Mount
• Size / Dimension:15.77" L x 4.06" W x 3.33" H (400.6mm x 103.0mm x 84.6mm)
• Approval Agency:-
• Standard Number:-
