B82801B0305A125

Image is for reference, please contact us to get the real picture

Manufacturer Part
B82801B0305A125
Manufacturer
TDK EPCOS
Description
CURR SENSE XFMR 1:125 SMD
Category
Transformers
Family
Current Sense Transformers
Series
-
In Stock
0
Datasheets
-

B82801B0305A125 Specifications

  • Series:B82801B
  • Package:Tape & Reel (TR)Cut Tape (CT)
  • Part Status:Active
  • Frequency Range:50kHz ~ 1MHz
  • Type:Invasive
  • Current Rating (Amps):-
  • Inductance:0.8mOhm Primary, 6.5Ohm Secondary
  • ET (Volt-Time):-
  • Turns Ratio - Primary:Secondary:Surface Mount
  • Current Ratio:0.280" L x 0.320" W (7.11mm x 8.13mm)
  • DC Resistance (DCR):0.200" (5.08mm)
  • Ratings:Gull Wing
