PC-16-75

Image is for reference, please contact us to get the real picture

Manufacturer Part
PC-16-75
Manufacturer
Signal Transformer
Description
PWR XFMR LAMINATED 1.2VA TH
Category
Transformers
Family
Power Transformers
Series
-
In Stock
0
Datasheets
-

PC-16-75 Specifications

  • Series:PC
  • Package:Box
  • Part Status:Active
  • Type:Laminated Core
  • Voltage - Primary:115V
  • Voltage - Secondary (Full Load):Parallel 8V, Series 16V
  • Current - Output (Max):Parallel 150mA, Series 75mA
  • Primary Winding(s):Single
  • Secondary Winding(s):Dual
  • Center Tap:No
  • Power - Max:1.2VA
  • Mounting Type:Through Hole
  • Termination Style:PC Pin
  • Size / Dimension:34.90mm L x 28.60mm W
  • Height - Seated (Max):30.15mm
  • Voltage - Isolation:1500Vrms
  • Weight:0.188 lb (85.28 g)
