PA0803NL

Image is for reference, please contact us to get the real picture

Manufacturer Part
PA0803NL
Manufacturer
PulseLarsen Antenna
Description
XFMR DC/DC CONV SMD
Category
Transformers
Family
Switching Converter, SMPS Transformers
Series
-
In Stock
0
Datasheets
-

PA0803NL Specifications

  • Series:PA08XXNL
  • Package:Tray
  • Part Status:Active
  • Type:For DC/DC Converters
  • Applications:-
  • Intended Chipset:-
  • Chipset Manufacturer:-
  • Voltage - Primary:18 ~ 76V
  • Voltage - Auxiliary:-
  • Voltage - Isolation:1500Vrms
  • Inductance @ Frequency:-
  • Frequency:200 ~ 700kHz
  • Operating Temperature:-40°C ~ 125°C
  • Mounting Type:Surface Mount
  • Size / Dimension:0.850" L x 0.920" W (21.60mm x 23.37mm)
  • Height - Seated (Max):0.348" (8.85mm)
  • Footprint:0.850" L x 0.920" W (21.60mm x 23.37mm)
  • Style:Planar
