8690030000

Image is for reference, please contact us to get the real picture

Manufacturer Part
8690030000
Manufacturer
Weidmuller
Description
RELAY GEN PURPOSE 3PDT 10A 24V
Category
Relays
Family
Power Relays, Over 2 Amps
Series
-
In Stock
0
Datasheets
-

8690030000 Specifications

  • Series:RCM
  • Package:Bulk
  • Part Status:Active
  • Mounting Type:Socketable
  • Coil Voltage:24VAC
  • Contact Form:3PDT (3 Form C)
  • Contact Rating (Current):10 A
  • Switching Voltage:400VAC - Max
  • Coil Current:41.6 mA
  • Coil Type:Non Latching
  • Features:Test Button
  • Termination Style:Plug In, Quick Connect - 0.110" (2.8mm)
  • Seal Rating:-
  • Coil Insulation:-
  • Must Operate Voltage:19.2 VAC
  • Must Release Voltage:7.2 VAC
  • Operate Time:15 ms
  • Release Time:10 ms
  • Operating Temperature:-40°C ~ 70°C
  • Contact Material:Silver Nickel (AgNi)
  • Relay Type:General Purpose
