TXS2SA-9V-Z

Image is for reference, please contact us to get the real picture

Manufacturer Part
TXS2SA-9V-Z
Manufacturer
Panasonic
Description
RELAY GEN PURPOSE DPDT 1A 9VDC
Category
Relays
Family
Signal Relays, Up to 2 Amps
Series
-
In Stock
0
Datasheets
-

TXS2SA-9V-Z Specifications

  • Series:TX-S
  • Package:Tape & Reel (TR)
  • Part Status:Active
  • Mounting Type:Surface Mount
  • Coil Voltage:9VDC
  • Contact Form:DPDT (2 Form C)
  • Contact Rating (Current):1 A
  • Switching Voltage:110VDC - Max
  • Coil Current:5.6 mA
  • Coil Type:Non Latching
  • Features:-
  • Termination Style:Gull Wing
  • Seal Rating:Sealed - Fully
  • Coil Insulation:-
  • Must Operate Voltage:7.2 VDC
  • Must Release Voltage:0.9 VDC
  • Operate Time:5 ms
  • Release Time:5 ms
  • Operating Temperature:-40°C ~ 70°C
  • Contact Material:Silver (Ag), Gold (Au)
  • Relay Type:General Purpose
